示例1
Example 1
第一届智能光学设计大赛
The 1st Intelligent Optical Design Competition
应用场景描述
Application Scenarios Description
大赛申报主题：基于Pancake系统的折反射成像系统
Theme: Catadioptric Imaging System Based on Pancake Lenses
申报人姓名（如多人，请写多个名字）：张明
Name (If there are multiple people, please write multiple names): Zhang Ming
申报单位：讯技光电科技（上海）有限公司
Units: INFOTEK SHANGHAI
应用领域（教育领域 / 科研领域 / 工业领域）: 科研领域
Applications(Education/R&D/Industry)：R&D
应用场景描述：
Application Scenarios Description：
基于Pancake系统的折反射成像系统
摘要
为了降低成本和重量，许多现代应用引入智能方法来使其光学系统小型化。该原理的一种创新实现是折叠成像系统，其中聚焦透镜的特性分布在多个组件之间。通过巧妙地操纵传播光束的偏振态，该系统允许多次内部反射，从而实现模拟更大透镜的功能。本示例我们定义了一组包含不同入射角度的平面波，然后将其通过系统传播计算出最终的焦点。
 系统描述
Catadioptric Imaging System Based on Pancake Lenses
Abstract
In order to reduce costs and weight, many modern application introduce smart ways to miniaturize their optical systems. One particular implementation of this principle is the folded imaging system, in which the property of a focusing lens is distributed between multiple components. By cleverly manipulating the polarizations status of the propagated light, this system allows for multiple internal reflection, mimicking the functionality of a much bigger lens. we defined a set of Plane Wave with different incident angles, which then are propagated through the system to calculate the focal spots at the end.
System Demonstrate
填写完成后，请将此文件与签字版大赛承诺书一并发送邮件至 virtuallab@infotek.com.cn ，邮件标题与本文件标题请保持一致。
After completing the filling, please send this document along with the signed version of the competition commitment via email to virtuallab@infotek.com.cn, Please keep the email title consistent with this file title.
应用场景描述撰写注意事项：
Notes on writing application scenario description:
1. 我们欢迎任意类型光学系统的投稿，不仅仅局限于该示例。
We welcome any type of optical system, not limited to this examples !
2. 请使用150-250字清晰简洁地描述您的场景，并用通过示意图来展示场景的建模和设计思路。
Please use 150-250 words for a clear and concise description of your scene and an illustration to demonstrate the modeling and design of the scenario.
3. 在您的场景描述或演示中，您需要清楚地描述光源是什么，元件是什么，要测量什么物理量，或者要达到什么目的。
In your scene description or demonstrate, you need to clearly describe what the light source is, what the component is, what the physical quantity is to be measured, or what the purpose is to be achieved.
4. 您的应用场景，需要提交中英文双语版本。
Your application scenario requires submission of bilingual versions in both Chinese and English.
您仅需提交以上信息即可，以下链接为该示例的完整描述，请您参考。
You only need to submit the content of the above information. The following link provides a complete description of the case for your reference:
基于Pancake系统的折反射成像系统 - 讯技光电科技(上海)有限公司 (infotek.com.cn) |
